IRAMY20UP60B

International Rectifier's IRAMY20UP60B is a 20A, 600V Integrated Power Hybrid IC with Internal Shunt Resistor for Appliance Motor Drives applications such as air conditioning systems and compressor drivers as well as for light industrial application. IR's technology offers an extremely compact, high performance AC motor-driver in a single isolated package to simplify design.

 Non Punch-Through IGBT technology and the industry This advanced HIC of the IRAMY20UP60B is a combination of IR's low V_CE(on) benchmark 3-Phase high voltage, high speed driver in a fully isolated thermally enhaced package.

A built-in temperature monitor and over-current and over-temperature protections, along with the short- circuit rated IGBTs and integrated under-voltage lockout function, deliver high level of protection and fail-safe operation. Using a new developed single in line package (SiP3) with heatspreader for the power die along with full transfer mold structure minimizes PCB space and resolves isolation problems to heatsink.
