IRF7389PBF

MOSFET

product image

IRF7389PBF Picture
See larger image
SeekIC No. : 00152190 Detail

IRF7389PBF: MOSFET

IRF7389PBF Data Sheet

floor Price/Ceiling Price

US $ .31~.84 / Piece | Get Latest Price
Part Number:
IRF7389PBF
Mfg:
International Rectifier
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~100
  • 100~250
  • Unit Price
  • $.84
  • $.52
  • $.36
  • $.31
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/5

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Transistor Polarity : N and P-Channel Drain-Source Breakdown Voltage : 30 V
Gate-Source Breakdown Voltage : 20 V Continuous Drain Current : 7.3 A
Resistance Drain-Source RDS (on) : 46 mOhms Configuration : Dual Dual Drain
Maximum Operating Temperature : + 150 C Mounting Style : SMD/SMT
Package / Case : SOIC-8 Packaging : Tube

Description

Mounting Style : SMD/SMT
Drain-Source Breakdown Voltage : 30 V
Continuous Drain Current : 7.3 A
Maximum Operating Temperature : + 150 C
Packaging : Tube
Gate-Source Breakdown Voltage : 20 V
Package / Case : SOIC-8
Transistor Polarity : N and P-Channel
Configuration : Dual Dual Drain
Resistance Drain-Source RDS (on) : 46 mOhms


Parameters:

Technical/Catalog InformationIRF7389PBF
VendorInternational Rectifier
CategoryDiscrete Semiconductor Products
Mounting TypeSurface Mount
FET PolarityN and P-Channel
Drain to Source Voltage (Vdss)30V
Current - Continuous Drain (Id) @ 25° C7.3A, 5.3A
Rds On (Max) @ Id, Vgs29 mOhm @ 5.8A, 10V
Input Capacitance (Ciss) @ Vds 650pF @ 25V
Power - Max2.5W
PackagingBulk
Gate Charge (Qg) @ Vgs33nC @ 10V
Package / Case8-SOIC (3.9mm Width)
FET Feature*
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names IRF7389PBF
IRF7389PBF
