IRF830

Transistor Polarity : N-Channel
Gate-Source Breakdown Voltage : +/- 20 V
Configuration : Single
Mounting Style : Through Hole
Maximum Operating Temperature : + 150 C
Packaging : Tube
Package / Case : TO-220AB
Drain-Source Breakdown Voltage : 500 V
Resistance Drain-Source RDS (on) : 1.5 Ohms
Continuous Drain Current : 4.5 A


Features:

·Dynamic dv/dt Rating
·Repetitive Avalanche Rated
·Fast Switching
·Ease of Paralleling
·Simple Drive Requirements




Specifications

	Parameter	Max.	Units
ID @ TC = 2	Continuous Drain Current, VGS @ 10V	2.5	A
ID @ TC = 100	Continuous Drain Current, VGS @ 10V	1.6
IDM	Pulsed Drain Current (1)	10
PD @TC = 25	Power Dissipation	50	W
	Linear Derating Factor	0.4	W/
	Linear Derating Factor ( PCB Mount, D2 ) (1)	0.025
VGS	Gate-to-Source Voltage	± 30	V
EAS	Single Pulse Avalanche Energy (2)	280	mJ
IAR	Avalanche Current (1)	4.5	A
EAR	Repetitive Avalanche Energy (1)	7.4	mJ
dv/dt	Peak Diode Recovery dv/dt (3)	3.4	V/ns
TJ TSTG	Operating Junction and Storage Temperature Range	-55 to + 150
	Soldering Temperature, for 10 seconds	300 (1.6mm from case )

Description

The Bay Linear MOSFET's of the IRF830 provide the designers with the best combination of fast switching, ruggedized device design, low 0n-resistance and low cost-effectiveness.

The IRF830 is offered in a 3-pin is universally preferred for all commercial-industrial applications at power dissipation level to approximately to 50 watts. Also, available in a D2 surface mount power package with a power dissipation up to 2 Watts





Parameters:

Technical/Catalog Information	IRF830
Vendor	STMicroelectronics
Category	Discrete Semiconductor Products
Mounting Type	Through Hole
FET Polarity	N-Channel
Drain to Source Voltage (Vdss)	500V
Current - Continuous Drain (Id) @ 25° C	4.5A
Rds On (Max) @ Id, Vgs	1.5 Ohm @ 2.7A, 10V
Input Capacitance (Ciss) @ Vds	610pF @ 25V
Power - Max	100W
Packaging	Tube
Gate Charge (Qg) @ Vgs	30nC @ 10V
Package / Case	TO-220-3 (Straight Leads)
FET Feature	Standard
Lead Free Status	Contains Lead
RoHS Status	RoHS Non-Compliant
Other Names	IRF830 IRF830 497 2732 5 ND 49727325ND 497-2732-5
