IRFB4332PBF

MOSFET MOSFT 250V 60A 33mOhm 99nC Qg

product image

IRFB4332PBF Picture
See larger image
SeekIC No. : 00149065 Detail

IRFB4332PBF: MOSFET MOSFT 250V 60A 33mOhm 99nC Qg

IRFB4332PBF Data Sheet

floor Price/Ceiling Price

US $ 1.11~2.28 / Piece | Get Latest Price
Part Number:
IRFB4332PBF
Mfg:
International Rectifier
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~100
  • 100~250
  • Unit Price
  • $2.28
  • $1.55
  • $1.16
  • $1.11
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Transistor Polarity : N-Channel Drain-Source Breakdown Voltage : 250 V
Gate-Source Breakdown Voltage : +/- 30 V Continuous Drain Current : 60 A
Resistance Drain-Source RDS (on) : 33 mOhms Configuration : Single
Maximum Operating Temperature : + 175 C Mounting Style : Through Hole
Package / Case : TO-220AB Packaging : Tube

Description

Transistor Polarity : N-Channel
Configuration : Single
Maximum Operating Temperature : + 175 C
Mounting Style : Through Hole
Packaging : Tube
Package / Case : TO-220AB
Drain-Source Breakdown Voltage : 250 V
Gate-Source Breakdown Voltage : +/- 30 V
Continuous Drain Current : 60 A
Resistance Drain-Source RDS (on) : 33 mOhms


Features:

` Advanced Process Technology
` Key Parameters Optimized for PDP Sustain, Energy Recovery and Pass Switch Applications
` Low EPULSE Rating to Reduce Power Dissipation in PDP Sustain, Energy Recovery and Pass Switch Applications
` Low QG for Fast Response
` High Repetitive Peak Current Capability for Reliable Operation
` Short Fall & Rise Times for Fast Switching
`175 Operating Junction Temperature for Improved Ruggedness
` Repetitive Avalanche Capability for Robustness and Reliability


Specifications

  Parameter Max. Units
VGS Gate-to-Source Voltage ±30 V
ID @ TC = 25 Continuous Drain Current, VGS @ 10V 60 A
ID @ TC = 100 Continuous Drain Current, VGS @ 10V 42
IDM Pulsed Drain Current 230
IRP @ TC =100 Repetitive Peak Current 120
PD @ TC = 25 Power Dissipation 390 W
PD @ TC = 25 Power Dissipation 200
  Linear Derating Factor 2.6 W/
TJ
TSTG		 Operating Junction
Storage Temperature Range		 -40 to 175
  Soldering Temperature, for 10 seconds 300
  Mounting Torque, 6-32 or M3 Screw 10lb`in (1.1N`m)) N
Repetitive rating; pulse width limited by max. junction temperature.
Half sine wave with duty cycle = 0.25, ton=1sec.


Parameters:

Technical/Catalog InformationIRFB4332PBF
VendorInternational Rectifier
CategoryDiscrete Semiconductor Products
Mounting TypeThrough Hole
FET PolarityN-Channel
Drain to Source Voltage (Vdss)250V
Current - Continuous Drain (Id) @ 25° C60A
Rds On (Max) @ Id, Vgs33 mOhm @ 35A, 10V
Input Capacitance (Ciss) @ Vds 5860pF @ 25V
Power - Max390W
PackagingTube
Gate Charge (Qg) @ Vgs150nC @ 10V
Package / CaseTO-220-3 (Straight Leads)
FET FeatureStandard
Drawing Number*
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names IRFB4332PBF
IRFB4332PBF
