IRU1030 Product Image

IRU Series Datasheet download

Five Points

Part Number: IRU1030



MFG: IR

Package Cooled: N/A

D/C: 40

Description: The IRU1030 is a low dropout three-terminal adjustable regulator with minimum of 3A output current cap...


Urgent Purchase

IRU1030 General Description


The IRU1030 is a low dropout three-terminal adjustable regulator with minimum of 3A output current capability. This product is specifically designed to provide well regulated supply for low voltage IC applications such as PentiumTM P54CTM, P55CTM as well as GTL+ termination for Pentium ProTM and KlamathTM processor applications. The IRU1030 is also well suited for other processors such as CyrixTM, AMD and Power PCTM applications. The IRU1030 is guaranteed to have <1.3V dropout at full load current making it ideal to provide well regulated outputs of 2.5V to 3.3V with 4.75V to 7V input supply.

IRU1030 Maximum Ratings

Input Voltage (VIN) ........................................................................... 7V
Power Dissipation ...................................................... Internally Limited
Storage Temperature Range ........................................ -65°C To 150°C
Operating Junction Temperature Range .......................... 0°C To 150°C

IRU1030 Features

·Guaranteed < 1.3V Dropout at Full Load Current
·Fast Transient Response
·1% Voltage Reference Initial Accuracy
·Output Current Limiting
·Built-In Thermal Shutdown

IRU1030 Typical Application

·Low Voltage Processor Applications such as:P54CTM, P55CTM, Cyrix M2TM,POWER PCTM, AMD
·GTL+ Termination
·PENTIUM PROTM, KLAMATHTM
·Low Voltage Memory Termination Applications
·Standard 3.3V Chip Set and Logic Applications

IRU1030 Connection Diagram

IRU1030 Connection Diagram
