ISD33000

Features: • Single-chip voice record/playback solution• Single +3 volt supply• Low-power consumption• Operating current: ICC Play = 25 mA (typical) ICC Rec = 30 mA (typical)• Standby current 1 A (typical)• Single-chip durations of 60, 75, 90 and 120 seconds; 2, ...

product image

ISD33000 Picture
SeekIC No. : 004379387 Detail

ISD33000: Features: • Single-chip voice record/playback solution• Single +3 volt supply• Low-power consumption• Operating current: ICC Play = 25 mA (typical) ICC Rec = 30 mA (typical)&...

floor Price/Ceiling Price

Part Number:
ISD33000
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/28

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• Single-chip voice record/playback solution
• Single +3 volt supply
• Low-power consumption
• Operating current:
         ICC Play = 25 mA (typical)
         ICC Rec = 30 mA (typical)
• Standby current 1 A (typical)
• Single-chip durations of 60, 75, 90 and 120 seconds; 2, 2.5, 3 and 4 minutes
• High-quality, natural voice/audio reproduction
• AutoMute feature provides background noise attenuation during periods of silence
• No algorithm development required
• Microcontroller SPI or Microwire serial interface
• Fully addressable to handle multiple messages
• Nonvolatile message storage
• Power consumption controlled by SPI or microwire control register
• 100-year message retention (typical)
• 100,000 record cycles (typical)
• On-chip clock source
• Available in die form, PDIP, SOIC and TSOP packaging
• Extended temperature (20°C to +70°C) and industrial
   temperature (40°C to +85°C) versions available



Application

• Cellular phones
• Personal Digital Recorders (PDR)
• Automotive
• Personal Digital Assistants (PDA)



Description

The ISD33000 ChipCorder® Series provides highquality, 3-volt, single-chip record/playback solutions for 1- to 4-minute messaging applications which are ideal for cellular phones and other portable products. The CMOS devices include an on-chip oscillator, antialiasing filter, smoothing filter, AutoMute® feature, audio amplifier and high density, multilevel storage array. The ISD33000 series is designed to be used in a microprocessoror microcontroller-based system. Address and control are accomplished through a Serial Peripheral Interface (SPI) or Microwire serial interface to minimize pin count.

Recordings are stored in on-chip nonvolatile memory cells, providing zero-power message storage. This unique, single-chip solution is made possible through ISD's patented multilevel storage technology. Voice and audio signals are stored directly into memory in their natural form, providing high-quality, solid-state voice reproduction.
