KD2406PHB2

FAN 24VDC 60MMX15.5MM

product image

KD2406PHB2 Picture
See larger image
SeekIC No. : 003442050 Detail

KD2406PHB2: FAN 24VDC 60MMX15.5MM

KD2406PHB2 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
KD2406PHB2
Mfg:
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/4

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Series: KD Manufacturer: Sunon Fans
Fan Type: Tubeaxial Size / Dimension: Square - 60mm L x 60mm H x 15.5mm W
Voltage - Rated: 24VDC Power (Watts): 1.90W
Features: - RPM: 4200 RPM
Noise: 31.5 dB(A) Package / Case : SOP-20
Static Pressure: 0.150 in H2O (37.4 Pa) Air Flow: 18.5 CFM (0.524m³/min)
Termination: 2 Wire Leads Bearing Type: Ball

Description

Manufacturer: Sunon Fans
Fan Type: Tubeaxial
Features: -
Static Pressure: 0.150 in H2O (37.4 Pa)
Termination: 2 Wire Leads
Operating Temperature: 14 ~ 158°F (-10 ~ 70°C)
Bearing Type: Ball
RPM: 4200 RPM
Voltage - Rated: 24VDC
Series: KD
Power (Watts): 1.90W
Noise: 31.5 dB(A)
Size / Dimension: Square - 60mm L x 60mm H x 15.5mm W
Air Flow: 18.5 CFM (0.524m³/min)


Parameters:

Technical/Catalog InformationKD2406PHB2
VendorSunon Fans
CategoryFans, Thermal Management
Voltage - Rated 24VDC
Power (Watts)1.3W
Bearing TypeBall
Size / DimensionSquare - 60mm L x 60mm H x 15mm W
Air Flow18 CFM
Features-
Termination2 Wire Leads
Fan TypeTubeaxial
RoHS StatusRoHS Non-Compliant
Other Names KD2406PHB2
KD2406PHB2
