Purchase KS8993M, In-stock KS8993M From SeekIC.
MFG:KENDIN Package Cooled:QFP
- Table of contents:
KS8993M
-
Suppliers
DataSheet
General Description
KS8993M Features
· Proven 2nd generation of Integrated 3-port 10/100 Ethernet switch with 3 MACs and 2 PHYs (2+1)
· Non-blocking architecture to assure fast packet delivery, with 1024 MAC address table lookup and packet forwarding via store-and-forward architecture
· MII registers can be accessed via MDIO bus or SPI bus
· MII interfaces support both a MAC mode or PHY mode or 7-wire (SNI) mode
· Automatic MDI/MDIX crossover for 100Base-TX and 10BaseT ports with disable and enable option
· Support 802.1Q VLAN up to 16 group
· 802.1p/q tag insertion or removal on a per port basis (egress)
· QoS / CoS packets prioritization supports: per port, 802.1P and DiffServ based
· Re-mapping of 802.1p priority field and VLAN ID field per port basis
· LED Indicators for link, activity, full/half duplex and speed
· Support Port Mirroring
· Advanced Rate limiting
· Management Information Base (MIB)
· Power Dissipation: < 200mA including Physical transmit drivers
· Plastic QFP 128 Package
· 1.8 volt for Vcc core and 3.3 volt for I/O
· Non-blocking architecture to assure fast packet delivery, with 1024 MAC address table lookup and packet forwarding via store-and-forward architecture
· MII registers can be accessed via MDIO bus or SPI bus
· MII interfaces support both a MAC mode or PHY mode or 7-wire (SNI) mode
· Automatic MDI/MDIX crossover for 100Base-TX and 10BaseT ports with disable and enable option
· Support 802.1Q VLAN up to 16 group
· 802.1p/q tag insertion or removal on a per port basis (egress)
· QoS / CoS packets prioritization supports: per port, 802.1P and DiffServ based
· Re-mapping of 802.1p priority field and VLAN ID field per port basis
· LED Indicators for link, activity, full/half duplex and speed
· Support Port Mirroring
· Advanced Rate limiting
· Management Information Base (MIB)
· Power Dissipation: < 200mA including Physical transmit drivers
· Plastic QFP 128 Package
· 1.8 volt for Vcc core and 3.3 volt for I/O
KS8993M Connection Diagram
