Purchase KSR2206, In-stock KSR2206 From SeekIC.
- Table of contents:
KSR2206
-
Suppliers
DataSheet
General Description
KSR2206 Maximum Ratings
| Symbol | Parameter | Value | Units |
| VCBO | Collector-Base Voltage | -50 | V |
| VCEO | Collector-Emitter Voltage | -50 | V |
| VEBO | Emitter-Base Voltage | -10 | V |
| IC | Collector Current | -100 | mA |
| PC | Collector Power Dissipation |
200 | mW |
| TJ | Junction Temperature | 150 | oC |
| TSTG | Storage Temperature | -55~150 | oC |
KSR2206 Typical Application
`Switching circuit, Inverter, Interface circuit, Driver Circuit
`Built in bias Resistor (R1=10K, R 2=47K)
`Complement to KSR1206
KSR2206
PDF/DataSheet Download
- Datasheet: KSR2206
- File Size: 38193 KB
- Manufacturer: SAMSUNG [Samsung semiconductor]
- Click here to Download
