The PAM3115ALA300 is designed as one kind of 1.5A low voltage-low dropout CMOS regulator device that can be used in wide range of applications such as (1)DSP, FPGA, and Microprocessor Power Supplies; (2)1.2V Core Voltage for DSPs; (3)SATA Power Supply; (4)LCD TV/ Monitors; (5)Wireless Devices; (6)Communication Devices; (7)Portable Electronics; (8)Post Regulator for SMPS. And this device is available in SOT-223, TO-252 and SOP-8(exposed pad) packages.

Features of the PAM3115ALA300 are:(1)Low-Dropout Regulator Supports Input Voltages Down to 1.4V;(2)Output Voltage Available in 0.9V, 1.0V, 1.2V, 1.5V, 1.8V, 2.5V,2.8V,2.85V,3.0V, 3.3V;(3)Stable with a Ceramic Output Capacitor of 1.0uF or Higher;(4)Low Dropout Voltage:150 mV @1.5A;(5)Low Quiescent Current;(6)Over Temperature Shutdown;(7)Short Circuit Protection;(8)Low Temperature Coefficient;(9)Standard SOT-223,TO-252 and SOP-8 (Exposed Pad) Packages;(10)Pb-Free Package.

The absolute maximum ratings of the PAM3115ALA300 can be summarized as:(1)Input Voltage: 4.0 V;(2)Output Pin Voltage: -0.3V to VIN+0.3V;(3)Operation Temperature Range: -40 to +85;(4)Operation Junction Temperature: -40 to +125;(5)Maximum Output Current: PD /(VIN - Vo );(6)Storage Temperature: -65 to +150;(7)Maximum Junction Temperature: +150;(8)Soldering Temperature: 300, 5sec. If you want to know more information such as the electrical characteristics about the PAM3115ALA300, please download the datasheet in www.seekic.com or www.chinaicmart.com.
