MFG:SANYD Package Cooled:DIP
MFG: SANYD
Package Cooled: DIP
Description: The LC7218, LC7218M and LC7218JM are PLL frequency synthesizers for electronic tuning. The LC7218,LC7218M and LC7218JM ...
|
Parameter |
Symbol |
Conditions |
Ratings |
Unit |
| Maximum supply voltage |
VDD max |
VDD |
0.3 to +7.0 |
V |
| Input voltage |
VIN(1) |
CE, CL, DI, IN0, IN1 |
0.3 to +7.0 |
V |
|
VIN(2) |
Input pins other than VIN (1) |
0.3 to VDD + 0.3 |
V | |
| Output voltage |
VOUT(1) |
DO, SYC |
0.3 to +7.0 |
V |
|
VOUT(2) |
OUT1, OUT2 |
0.3 to VDD + 0.3 |
V | |
|
VOUT(3) |
OUT3 to OUT6, OUT0 |
0.3 to +15 |
V | |
|
VOUT(4) |
Output pins other than VOUT(1),VOUT(2)and VOUT(3) |
0.3 to VDD + 0.3 |
V | |
| Allowable power dissipation |
Pd max |
Ta 85°C :LC7218 |
350 |
mW |
| :LC7218M |
300 | |||
| :LC7218JM |
200 | |||
| Operating temperature |
Topr |
-40to+85 |
°C | |
| Storage temperature |
Tstg |
-55to+125 |
°C |
• These products feature a rich set of built-in functions for AV applications, including reference frequency and unlock detection circuits, I/O ports and a generalpurpose counter.
LC7218
PDF/DataSheet Download
Features of the LC7216M are:(1)programmable divider;(2)reference frequency:10 user selectable reference frequencies;(3)output port:5 ports,2 complementary outputs,3N-channel open drain outputs;(4)input port:2 ports;(5)universal counter;(6)unlock detection fo...
The LC72151V is a PLL frequency synthesizer for car audio systems. It can implement high-performance multifunction tuners such as RDS tuners and features a fast locking circuit.
