Description: The LF111, LF211 and LF311 are FET input voltage com- parators that virtually eliminate input current ...
The LF111, LF211 and LF311 are FET input voltage com- parators that virtually eliminate input current errors. De- signed to operate over a 5.0V to g15V range the LF111 can be used in the most critical applications.
The extremely low input currents of the LF111 allows the use of a simple comparator in applications usually requiring input current buffering. Leakage testing, long time delay cir- cuits, charge measurements, and high source impedance voltage comparisons are easily done.
Further, the LF111 can be used in place of the LM111 elimi-nating errors due to input currents. See the ''application hints'' of the LM311 for application help.
If Military/Aerospace specified devices are required,please contact the National Semiconductor Sales Office/Distributors for availability and specifications.
(Note 8)
LF111/LF211 LF311
Total Supply Voltage (V84) 36V 36V
Output to Negative Supply
Voltage (V74) 50V 40V
Ground to Negative Supply
Voltage (V14) 30V 30V
Differential Input Voltage ±30V ±30V
Input Voltage (Note 1) ±15V ±15V
Power Dissipation (Note 2) 500 mW 500 mW
Output Short Circuit Duration 10 seconds 10 seconds
perating Temp.
Range
LF111 -55to +125
LF211 -25to +85
LF311 0to a70
Storage Temp.
Range -65to+150 -65to +150
Lead Temp.
(Soldering,
10 seconds) 260 260
ESD rating to be determined.
