LM138K

Linear Regulators - Standard 1.2-32V Adj Positive

product image

LM138K Picture
SeekIC No. : 00503301 Detail

LM138K: Linear Regulators - Standard 1.2-32V Adj Positive

floor Price/Ceiling Price

US $ 5.43~7.7 / Piece | Get Latest Price
Part Number:
LM138K
Mfg:
STMicroelectronics
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~10
  • 10~100
  • 100~250
  • Unit Price
  • $7.7
  • $6.58
  • $5.99
  • $5.43
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/3/28

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Output Type : Adjustable Polarity : Positive
Output Voltage : 1.2 V to 32 V Output Current : 5 A
Load Regulation : 0.1 % Input Voltage MAX : 35 V
Line Regulation : 0.005 % / V Maximum Operating Temperature : + 150 C
Mounting Style : Through Hole Package / Case : TO-3

Description

Polarity : Positive
Maximum Operating Temperature : + 150 C
Output Type : Adjustable
Mounting Style : Through Hole
Input Voltage MAX : 35 V
Output Voltage : 1.2 V to 32 V
Package / Case : TO-3
Output Current : 5 A
Load Regulation : 0.1 %
Line Regulation : 0.005 % / V


Description

The LM138K is a product of The LM138 subseries.The LM138 series of adjustable 3-terminal positive voltage regulators is capable of supplying in excess of 5A over a 1.2V to 32V output range. They are exceptionally easy to use and require only 2 resistors to set the output voltage.Careful circuit design has resulted in outstanding load and line regulation-comparable to many commercial power supplies. The LM138 family is supplied in a standard 3-lead transistor package.A unique feature of the LM138 family is time-dependent current limiting. The current limit circuitry allows peak currents of up to 12A to be drawn from the regulator for short periods of time. This allows the LM138 to be used with heavy transient loads and speeds start-up under full-load conditions.Under sustained loading conditions, the current limit decreases to a safe value protecting the regulator. Also included on the chip are thermal overload protection and safe area protection for the power transistor. Overload protection remains functional even if the adjustment pin is accidentally disconnected. Normally, no capacitors are needed unless the device is situated more than 6 inches from the input filter capacitors in which case an input bypass is needed. An output capacitor can be added to improve transient response, while bypassing
the adjustment pin will increase the regulator's ripple rejection.

Features of the LM138K are:(1)Guaranteed 7A peak output current;(2)Guaranteed 5A output current;(3)Adjustable output down to 1.2V;(4)Guaranteed thermal regulation;(5)Current limit constant with temperature;(6)P+ Product Enhancement tested;(7)Output is short-circuit protected.

The absolute maximum ratings of the LM138K can be summarized as:(1)Power Dissipation:Internally limited;(2)Input/Output Voltage Differential:+40V, -0.3V;(3)Storage Temperature:-65°C to +150°C;(4)Lead Temperature Metal Package (Soldering, 10 seconds):300°C;(5)Lead Temperature Plastic Package (Soldering, 4 seconds):260°C;(6)ESD Tolerance:TBD.




Parameters:

Technical/Catalog InformationLM138K
VendorSTMicroelectronics
CategoryIntegrated Circuits (ICs)
Regulator TypeSingle Output
Package / CaseTO-204, TO-3
PackagingTray
Regulator TopologyPositive Adjustable
Current - Output5A
Voltage - Output1.2 ~ 32 V
Operating Temperature-55°C ~ 150°C
Voltage - Input-
Number of Regulators1
Current - Limit (Min)7A
Current Short Circuit (Isc)-
Drawing Number*
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names LM138K
LM138K
497 6706 ND
4976706ND
497-6706
