Position: Home > Datasheet list > LM2 Series > Index L > LM2854MH-500/NOPB
Electronica China

Purchase LM2854MH-500/NOPB, In-stock LM2854MH-500/NOPB From SeekIC.

MFG:National Semiconductor  Category:Integrated Circuits (ICs)

LM2854MH-500/NOPB

LM2 Series Datasheet download

Five Points

Part Number: LM2854MH-500/NOPB

Category: Integrated Circuits (ICs)

MFG: National Semiconductor





Descriptions: IC REG 4A SYNC SMPL SW 16ETSSOP

Price Break

1
25
100
250
500
1000
5000
10000

Unit Price

5.35000
4.06600
3.10300
2.84620
2.72850
2.69640
2.62150
2.56800

Extended Price

5.35
101.65
310.30
711.55
1364.25
2696.40
13107.50
25680.00

(All prices are in USD) Prices for reference only
Urgent Purchase

LM2854MH-500/NOPB General Description

IC REG 4A SYNC SMPL SW 16ETSSOP

LM2854MH-500/NOPB Parameters

Technical/Catalog InformationLM2854MH-500/NOPB
VendorNational Semiconductor
CategoryIntegrated Circuits (ICs)
TypeStep-Down (Buck)
Number of Outputs1
Voltage - Input2.95 ~ 5.5 V
Voltage - OutputAdj down to 0.8V
Current - Output4A
Power - Output-
Package / Case16-TSSOP Exposed Pad, 16-eTSSOP, 16-HTSSOP
PackagingTube
Internal Switch(s)Yes
SynchronousYes
Rds (On)34 mOhm (N-Chan), 35 mOhm (P-Chan)
Operating Temperature-40°C ~ 125°C
Frequency - Switching500kHz
Drawing Number14; MXA16A; ; 16
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names LM2854MH 500 NOPB
LM2854MH500NOPB
LM2854MH 500 ND
LM2854MH500ND
LM2854MH-500
