Features: Tiny SOT23-5 package saves spaceVery wide common mode input rangeSpecified at 2.7V, 5V, and 10VTypical supply current 25 µA at 5V 50 kHz gain-bandwidth at 5VSimilar to popular LMC6462 Output to within 20 mV of supply rail at 100k loadGood capacitive load driveApplication Mobile com...
LMC7111: Features: Tiny SOT23-5 package saves spaceVery wide common mode input rangeSpecified at 2.7V, 5V, and 10VTypical supply current 25 µA at 5V 50 kHz gain-bandwidth at 5VSimilar to popular LMC646...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
ESD Tolerance SOT23-5 (Note 2)..................... 2000V
ESD Tolerance DIP Package
(Note 2) ...........................................................1500V
Differential Input Voltage ±Supply Voltage
Voltage at Input/Output Pin (V+) + 0.3V, (V−) − 0.3V
Supply Voltage (V+ − V−) ....................................11V
Current at Input Pin ........................................±5 mA
Current at Output Pin (Note 3) .....................±30 mA
Current at Power Supply Pin ...........................30 mA
Lead Temp. (Soldering, 10 sec.) ....................260°C
Storage Temperature Range .......−65°C to +150°C
Junction Temperature (Note 4) .......................150°C
The LMC7111 is a micropower CMOS operational amplifier available in the space saving SOT 23-5 package. This makes the LMC7111 ideal for space and weight critical designs. The wide common-mode input range makes it easy design battery monitoring circuits which sense signals above the V+ supply. The main benefits of the Tiny package are most apparent in small portable electronic devices, such mobile phones, pagers, and portable computers. The tiny amplifiers can be placed on a board where they are needed, simplifying board layout.
