LP5524

PinoutSpecificationsRegulated LEDs4LED ConfigurationParallelCurrent Matching0.5%Total LED Current100 mAInput Min Voltage2.7 VoltInput Max Voltage5.5 VoltPWM BrightCtrlYesAnalog-V BrightCtrlNoAmbient Light CompensationNoRGB-LEDNoTemperature Min-40 deg CTemperature Max85 deg CRegTypeLighting Managem...
