Purchase LS509, In-stock LS509 From SeekIC.
Part Number: LS509
Description: The hybrid consists of an LS509 amplifier, four capacitors, and two selectable bias resistors. The values of the ...
- Table of contents:
LS509
-
Suppliers
DataSheet
General Description
LS509 General Description
The hybrid consists of an LS509 amplifier, four capacitors, and two selectable bias resistors. The values of the capacitors assure proper operation of the circuit for the most commonly required frequency responses.
If a different frequency response is required, external components can be easily connected to the additional solder pads connected to various amplifier access points.
The jumper connection of the on-chip 125 Ω resistor and additional two resistors (58 Ω and 98 Ω) on the hybrid allow adjustment of the transducer bias current of the receiver.
LS509 Maximum Ratings
| PARAMETER | VALUE / UNITS |
| Supply Voltage | 3 VDC |
| Power Dissipation | 25 mW |
| Operating Temperature Range | -10° C to 40° C |
| Storage Temperature Range | -20° C to 70° C |
LS509 Features
•Gennum's LS509 3 stage amplifier
•independent preamp can be used as telecoil preamplifier
•four "must use" capacitors mounted on hybrid
•choice of 3 resistors to set transducer current
•easy assembly and high reliability
•independent preamp can be used as telecoil preamplifier
•four "must use" capacitors mounted on hybrid
•choice of 3 resistors to set transducer current
•easy assembly and high reliability
