LSC429052DW

The LSC429052DW is laser module. It is highly reliable fiber optic light sources operating in the 1300 nanometer band.  The internal semiconductor lasers are based upon InGaAsP buried heterostructure (BH) technology and fabricated by the Metal Organic Vapor Phase Epitaxy(MOVPE) process, resulting in long lifetimes and modest threshold currents.

The features of LSC429052DW can be summarized as:(1)1 Milliwatt Optical Output at 25 mA above Threshold, 25°C; (2)Center Wavelength between 1280 nm and 1330 nm; (3)Wide Operating Temperature Range: -40°C to +85°C.

The absolute maximum ratings of LSC429052DW are:(1)Laser Forward Current:150mA; (2)Laser Reverse Current:100A; (3)Laser Reverse Voltage:2V; (4)Photodiode Reverse Voltage:10V; (5)Photodiode Forward Current:1mA; (6)Operating Temperature (Case):-40°C to +85°C; (7)Storage Temperature:-40°C to +85°C; (8)Fiber Pull Strength:10N.

If you want to know more information such as the electrical characteristics about the LSC429052DW, please download the datasheet in www.seekic.com or www.chinaicmart.com .
