LWT-50H-5FF, US $ 136.59-136.59, LWT-50H-5FF DataSheet download, circuit diagram from SeekIC.com

See larger image

SeekIC No. : 003806722 Detail

LWT-50H-5FF: PWR SUP 50W +5 +15 -15V TRIPLE

LWT-50H-5FF Data Sheet

US $ 136.59~136.59 / Piece | Get Latest Price

Part Number:: LWT-50H-5FF
Mfg:
Supply Ability:: 5000

Price Break

Qty
0~1

Unit Price
$136.59

Processing time
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/4/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

LWT-15H-522 evaluate
US $81 - 93 / Piece

Linear and Switching Power Supplies 15W 5V 12V 3A
LWT-15H-525 evaluate
US $81 - 93 / Piece

Linear and Switching Power Supplies 15W 5V 12V 3A
LWT-15H-5FF evaluate
US $81 - 93 / Piece

Linear and Switching Power Supplies 15W 5V 15V 3A

Product Details

Quick Details

Supply Voltage - Max :	28 V	Series:	LW
Manufacturer:	TDK-Lambda Americas Inc	Type:	Standard Product
Number of Outputs:	3	Voltage - Output:	5V, ±15V
Voltage - Input:	85 ~ 265VAC	Output - 1 @ Current (Max):	5 VDC @ 8A
Output - 2 @ Current (Max):	15 VDC @ 1.5A	Output - 3 @ Current (Max):	-15 VDC @ 1A
Output - 4 @ Current (Max):	-	Power (Watts):	50W
Power Supply Type:	Switching (Open Frame)	Applications:	Commercial
Mounting Type:	Chassis Mount	Size / Dimension:	6.29" L x 3.82" W x 1.02" H (159.7mm x 97.0mm x 26.0mm)
Operating Temperature:	0°C ~ 60°C

Description

Type: Standard Product
Output - 4 @ Current (Max): -
Power Supply Type: Switching (Open Frame)
Applications: Commercial
Mounting Type: Chassis Mount
Output - 1 @ Current (Max): 5 VDC @ 8A
Power (Watts): 50W
Operating Temperature: 0°C ~ 60°C
Number of Outputs: 3
Manufacturer: TDK-Lambda Americas Inc
Voltage - Input: 85 ~ 265VAC
Voltage - Output: 5V, ±15V
Output - 2 @ Current (Max): 15 VDC @ 1.5A
Efficiency: 72%
Output - 3 @ Current (Max): -15 VDC @ 1A
Series: LW
Size / Dimension: 6.29" L x 3.82" W x 1.02" H (159.7mm x 97.0mm x 26.0mm)

Parameters:

Technical/Catalog Information	LWT-50H-5FF
Vendor	TDK-LAMBDA AMERICAS INC
Category	Power Supplies
Number of Outputs	3
Power (Watts)	50W
Voltage - Output	5V, 15V, -15V
Voltage - Input	85 ~ 265VAC
Power Supply Type	Switching (Open Frame)
1st Output	5 VDC @ 8A
2nd Output	15 VDC @ 1.5A
3rd Output	-15 VDC @ 1A
4th Output	-
Mounting Type	Chassis Mount
Other Names	LWT 50H 5FF LWT50H5FF 285 1024 ND 2851024ND 285-1024
