MFG:ST Package Cooled:BGA0812 D/C:99+
MFG: ST
Package Cooled: BGA0812
D/C: 99+
Description: The M36W216TI is a low voltage Multiple Memory Product which combines two memory devices; a 16 Mbit bo...
The M36W216TI is a low voltage Multiple Memory Product which combines two memory devices; a 16 Mbit boot block Flash memory and a 2 Mbit
SRAM. Recommended operating conditions do not allow both the Flash memory and the SRAM memory to be active at the same time.
The memory is offered in a Stacked LFBGA66 (12x8mm, 8 x 8 active ball, 0.8 mm pitch) package and is supplied with all the bits erased (set to '1').
|
Symbol |
Parameter |
Value |
Unit | |
|
Min |
Max | |||
|
TA |
Ambient Operating Temperature (1) |
40 |
85 |
°C |
|
TBIAS |
Temperature Under Bias |
40 |
125 |
°C |
|
TSTG |
Storage Temperature |
55 |
150 |
°C |
|
VIO |
Input or Output Voltage |
0.5 |
VDDQF +0.5 |
V |
|
VDDF1 , VDDQF |
Flash Supply Voltage |
0.5 |
3.8 |
V |
|
VPPF |
Program Voltage |
0.6 |
13 |
V |
|
VDDS |
SRAM Supply Voltage |
0.5 |
3.8 |
V |
Note: 1. Depends on range.
M36W216TI
PDF/DataSheet Download
The M36W216TI is a low voltage Multiple Memory Product which combines two memory devices; a 16 Mbit boot block Flash memory and a 2 MbitSRAM. Recommended operating conditions M36W216TIdo not allow both the Flash memory and the SRAM memory to be active at the...
