M51408SP

The M51408SP is a single-chip semiconductor integrated circuit with signal processing capabilities compatible with both PAL and NTSC type color televisions.It features a variety of signal processing functions including video IF,sound IF,picture,color,and deflection signal processing.It also combines tuner and simple transistor output level to facilitate practical PAL/NTSC type color television set design.

Recommended operating condition of the M51408SP are:(1)the supply vpltage range is 8.5 to 9.5V;(2)the rated supply voltage is 9.0V;(3)the current range is 15 to 22 mA;(4)the rated current is 18 mA.

The absolute maximum ratings of the M51408SP can be summarized as:(1):the symbol is VCC,the parameter is supply voltage,the rating is 10.8,the unit is V;(2):the symbol is Pd,the parameter is power dissipation,the rating is 1.4,the unit is W;(3):the symbol is Topr,the parameter is operating temperature,the rating is -20 to 65,the unit is ;(4):the symbol is Tstg,the parameter is storage temperature,the rating is -40 to 125,the unit is .
