General Description
M51943AGP General Description
M51943A are semiconductor integrated circuits designed for detecting supply voltage and resetting all types of logic circuits such as CPUs.
They find extensive applications,including battery checking circuits, level detecting circuit and waveform shaping circuit.
M51943AGP Maximum Ratings
| Symbol | Parameter | Test condition |
Ratings |
Unit | |
| ICC | Supply Voltage |
18 |
V | ||
| Isink | Output Sink Current |
6 |
mA | ||
| VO | Output Voltage | Output with constant current load |
Vcc |
V | |
| Pd | Power Dissipation | 5pin SOP(SOT-25) |
200 |
mW | |
| K | Thermal Derating | Ta 25 | 5pin SOP |
2 |
mW/ |
| Topr | Operating Temperature |
-30 to +85 |
|||
| Tstg | Storage Temperature |
-40 to +125 |
|||
M51943AGP Features
• Few external parts
• Detecting Voltage ...4.25V typ. (4.05V to 4.45V)
• Low threshold operating voltage (Supply voltage to keep
low-state at low supply voltage) .0.6V(TYP.) at RL=22k
• Wide supply voltage range .... 2 to 17V
• Sudden change in power supply has minimal effect on the ICs
• Wide application range
• Extra small package (SOT-25)
(M51943ASL:3pin SIP,M51943AML:3pin SOP, M51943AL:5pin SIPalready Mass production)
• Detecting Voltage ...4.25V typ. (4.05V to 4.45V)
• Low threshold operating voltage (Supply voltage to keep
low-state at low supply voltage) .0.6V(TYP.) at RL=22k
• Wide supply voltage range .... 2 to 17V
• Sudden change in power supply has minimal effect on the ICs
• Wide application range
• Extra small package (SOT-25)
(M51943ASL:3pin SIP,M51943AML:3pin SOP, M51943AL:5pin SIPalready Mass production)
M51943AGP Typical Application
• Reset pulse generation for almost all logic circuits
• Battery checking, level detecting, waveform shaping circuits
• Delayed waveform generator
• Switching circuit to a back-up power supply
• DC/DC converter
• Over voltage protection circuit
• Battery checking, level detecting, waveform shaping circuits
• Delayed waveform generator
• Switching circuit to a back-up power supply
• DC/DC converter
• Over voltage protection circuit
M51943AGP Connection Diagram
M51943AGP
PDF/DataSheet Download
- Datasheet: M51943AGP
- File Size: 13718 KB
- Manufacturer: MITSUBISHI [Mitsubishi Electric Semiconductor]
- Click here to Download
