M52001SP

The M52001SP is a semiconductor integrated that automatic selection and waveform shaping of 3 types of sync signal input:separate sync(positive/negative polarites 1 to 5Vp-p),composite sync(positive/negative polarites 1 to 5Vp-p) and sync video(sync negative).This IC is best suited to sync signal processing in auto tracking type display monitors.

recommended operating condition of the M52001SP are:(1)supply voltage range is 11.2 to 13V;(2)rated supply voltage is 12V,5V(output stage).

The maximum ratings of the M52001SP can be summarized as:(1):the symbol is VCC,the parameter is supply voltage,the rating is 14,the unit is V;(2):the symbol is Pd,the parameter is power dissipation,the rating is 1333,the unit is mW;(3):the symbol is Topr,the parameter is operating temperature range,the rating is -20 +75,the unit is ;(4):the symbol is Tstg,the parameter is storage temperature range,the rating is -40 to +125,the unit is .
