MFG:MIT Package Cooled:SIP
MFG: MIT
Package Cooled: SIP
Description: The M54543AL is a semiconductor IC capable of directly driving a smallsize bi-directional motor for forward/reverse rot...
| Symbol | Parameter | Conditions |
Ratings |
Unit | |
|
VCC (1) |
Supply voltage (1) |
-0.5 to +16 |
V | ||
|
VCC (2) |
Supply voltage (2) | With an external heat sink (3000mm2*1.5mm) |
-0.5 to +20 |
W | |
|
VCC' |
Driver supply voltage |
-0.5 to +16 |
V | ||
|
VI |
Input voltage |
0 to VCC |
V | ||
|
VO |
Output voltage |
-0.5 to VCC'+2.5 |
V | ||
|
IO (max) |
Peak output current | top=10ms : Repetitive cycle 0.2Hz max |
±1.5 |
A | |
|
IO (1) |
Continuous output current (1) |
±330 |
mA | ||
|
IO (2) |
Continuous output current (2) | With an external heat sink (3000mm2*1.5mm) |
±600 |
mA | |
|
Pd |
Power dissipation | Ta=75°C |
1.15 |
W | |
|
Topr |
Operating temperature |
10 to +75 |
°C | ||
|
Tstg |
Storage temperature |
-55 to +125 |
°C | ||
M54543AL
PDF/DataSheet Download
