MFG:MIT Package Cooled:SIP-9 D/C:83+
MFG: MIT
Package Cooled: SIP-9
D/C: 83+
Description: The M54543L is a semiconductor IC capable of directly driving a smallsize bi-directional motor for forward/reverse rota...
| Symbol | Parameter | Conditions |
Ratings |
Unit | |
|
VCC (1) |
Supply voltage (1) |
-0.5 to +16 |
V | ||
|
VCC (2) |
Supply voltage (2) | With an external heat sink (3000mm2*1.5mm) |
-0.5 to +20 |
W | |
|
VCC' |
Driver supply voltage |
-0.5 to +16 |
V | ||
|
VI |
Input voltage |
0 to VCC |
V | ||
|
VO |
Output voltage |
-0.5 to VCC'+2.5 |
V | ||
|
IO (max) |
Peak output current | top=10ms : Repetitive cycle 0.2Hz max |
±1.2 |
A | |
|
IO (1) |
Continuous output current (1) |
±330 |
mA | ||
|
IO (2) |
Continuous output current (2) | With an external heat sink (3000mm2*1.5mm) |
±600 |
mA | |
|
Pd |
Power dissipation | Ta=75°C |
1.15 |
W | |
|
Topr |
Operating temperature |
10 to +75 |
°C | ||
|
Tstg |
Storage temperature |
-55 to +125 |
°C | ||
M54543L
PDF/DataSheet Download
The M54543AL is a semiconductor IC capable of directly driving a smallsize bi-directional motor for forward/reverse rotation.
The M54543AFP is a semiconductor integrated circuit that is capable of directly driving a smallsize bi-directional motor rotating in both forward and reverse directions.
The M54542L ,BI-DIRECTIONAL MOTOR DRIVER,consists of a full bridge power driver designed for D-C motor control.The M54542L,full bridge motor driver,has the logic circuitry and darlington-pair power drivers for bidirectional control of D-C motors operating at...
M54539P six-circuit transistor arrays. The circuits are made of NPN transistors. Both the semiconductor integrated circuits perform high-current driving with extremely low inputcurrent supply.
M54534P and M54534FP are six-circuit transistor arrays.The circuits M54534P and M54534FP are made of NPN transistors. Both the semiconductor integrated circuits perform high-current driving withextremely low input-current supply.
M54534P and M54534FP are six-circuit transistor arrays.The circuits M54534P and M54534FP are made of NPN transistors. Both the semiconductor integrated circuits perform high-current driving withextremely low input-current supply.
