MFG:MITSUBIS.. Package Cooled:SOP D/C:09+
MFG: MITSUBIS..
Package Cooled: SOP
D/C: 09+
Description: M54564P and M54564FP are eight-circuit output-sourcing Darlington transistor arrays. The circuits are ...
M54564P and M54564FP are eight-circuit output-sourcing Darlington transistor arrays. The circuits are made of PNP and NPN transistors. Both the semiconductor integrated circuits perform high-current driving with extremely low inputcurrent supply.
|
Symbol |
Parameter |
Conditions |
Ratings |
Unit | |
|
VCEO |
Collector-emitter voltage | Output, L |
0.5 ~+50 |
V | |
|
VS |
Supply voltage |
50 |
W | ||
|
VI |
Input voltage |
0.5 ~ +30 |
V | ||
|
IO |
Output current | Current per circuit output, H |
500 |
mA | |
|
Pd |
Power dissipation | Ta = 25°C, when mounted on board |
1.79(P)/1.10(FP) |
W | |
|
Topr |
Operating temperature |
20 ~ +75 |
°C | ||
|
Tstg |
Storage temperature |
55 ~ +125 |
°C | ||
Drives of relays, printers, LEDs, fluorescent display tubes and lamps, and interfaces between MOS-bipolar logic systems and relays, solenoids, or small motors
M54564FP
PDF/DataSheet Download
M54563FP is an eight-circuit output-sourcing Darlington transistor array. The circuits are made of PNP and NPN transistors. This semiconductor integrated circuit performs highcurrent driving with extremely low input-current supply.
M54563FP is an eight-circuit output-sourcing Darlington transistor array. The circuits are made of PNP and NPN transistors. This semiconductor integrated circuit performs highcurrent driving with extremely low input-current supply.
M54562P and M54562FP are eight-circuit output-sourcing Darlington transistor arrays. The circuits are made of PNP and NPN transistors. Both the semiconductor integrated circuits perform high-current driving with extremely low inputcurrent supply.
M54562P and M54562FP are eight-circuit output-sourcing Darlington transistor arrays. The circuits are made of PNP and NPN transistors. Both the semiconductor integrated circuits perform high-current driving with extremely low inputcurrent supply.
M54561P is seven-circuit output-sourcing Darlington transistor arrays. The circuits are made of PNP and NPN transistors. Both the semiconductor integrated circuits perform high-current driving with extremely low input-current supply.
The M54560P 7-channel source driver,consists of 7 PNP and 7 PNP trasistors,connected to form high current gain driver with PNP action.The M54560P is comprised of seven PNP-NPN darlington source driver pairs with 20k series input resistors.Each output has an ...
