MFG:MOT Package Cooled:DIP D/C:07+
MFG: MOT
Package Cooled: DIP
D/C: 07+
Description: The M62501P/FP is a controller for a deflection system of CRT display monitors. It performs a stable P...
The M62501P/FP is a controller for a deflection system of CRT display monitors. It performs a stable PWM control over a wide fluctuation of external signals, thanks to the built-in trigger mode oscillator. The IC is suitable for an application to a high voltage drive of monitors because of its following circuits and functions;
• low voltage mulfunction protection circuit,
• over or under voltage protection circuit for a control line,
• soft-start function.
It is also applicable to a horizontal output correction.
| Symbol | Parameter | Conditions | Ratings | Unit | |
| VCC | Supply voltage | 15 | V | ||
| VOUT | Output voltage | 15 | V | ||
| IOUT | Output current | ±100 | mA | ||
| VICM | Error Amplifier input common mode voltage |
-0.3 ~ VCC | V | ||
| VID | Error Amplifier differential input voltage |
VCC | V | ||
| Pd | Power dissipation | P | FP | mW | |
| 1200 | 650 | ||||
| Kø | Thermal derating | Ta 25°C | P | FP | mW/°C |
| 9.6 | 5.2 | ||||
| Topr | Operrating temperature | -20 ~ +75 | °C | ||
| Tstg | Storage Temperature | -40 ~ +150 | °C | ||
