MFG:MIT Package Cooled:03+ D/C:2257
MFG: MIT
Package Cooled: 03+
D/C: 2257
Description: The M62782GP is a voltage threshold detector designed for detection of a supply voltage and generation...
The M62782GP is a voltage threshold detector designed for detection of a supply voltage and generation of a system reset pulse for almost all logic circuits such as microprocessor.
It also has extensive applications including battery checking, level detecting and waveform shaping circuits.
| Symbol | Parameter | Test condition | Ratings | Unit | |
| Vcc | Supply Voltage |
|
8 | V | |
| Isink | Output Sink Current |
|
6 | mA | |
| VO | Output Voltage | Output with open collector | 8 | V | |
| Pd | Power Dissipation | 3pin SOP(SOT-23) | 200 | mW | |
| K | Terminal derating | Ta25°C | 2 | mW/°C | |
| Topr | Operating Temperature |
|
-30 to +85 | °C | |
| Tstg | Storage Temperature |
|
-40 to +125 | °C |
• Few external parts
• Low threshold operating voltage (Supply voltage to keep low-state at low supply voltage) .0.65V(TYP.) at RL=22k
• Wide supply voltage range ...1.5to 7.0V
• Sudden change in power supply has minimal effect on the ICs
• Wide application range
• Extra small 5-pin package (5-pin SOP) .SOT-25
• Built-in long delay time .... 100 ms
M62782GP
PDF/DataSheet Download
