MA2420
-
Suppliers
DataSheet
General Description
MA2420 Maximum Ratings
|
Item |
Symbol |
Conditions |
Ratings |
Unit | |
|
P Class |
N Class | ||||
| Storage Temperature |
Tstg |
|
-30~125 |
-30~125 |
|
| Operating Temperature |
Top |
Case Temperature |
-20~125 |
-20~125 |
|
| Junction Temperature |
Tj |
|
150 |
150 |
|
| Peak Input Voltage |
Vin |
+,-,Fig.1 is Measurement Circuit of Peak Input Voltage Vin and Collector Cutoff Current ICEX. |
500 |
500 |
V |
| Input Current |
Iin |
Pulse Pulse Width 150s MAX, Duty1/2, Sawtooth Wave, Peak Value, +,- |
6 |
6 |
A |
| Maximum Operating Frequency |
f(max) |
|
200 |
200 |
kHZ |
| Maximum Power Dissipation |
PD |
Ta=25 |
3 |
3 |
W |
|
PD |
Heatsink Tc=100 |
12 |
12 |
W | |
| Dielectric Strength |
Vdis |
Terminals To Case AC 1 min |
2 |
2 |
kV |
| Insulation Resistance |
|
Terminals To Case 500VDC |
100 |
100 |
M |
| Fold Back Control Voltage |
VCONT(max) |
Fold Control Resistance=0 Duty 1/2, , |
±8 |
±8 |
V |
| Fold Back Control Current |
ICONT(max) |
-,+ |
100 |
100 |
mA |
MA2420
PDF/DataSheet Download
- Datasheet: MA2420
- File Size: 460214 KB
- Manufacturer: SHINDENGEN [Shindengen Electric Mfg.Co.Ltd]
- Click here to Download
