Part Number: MAX4574

Description: The MAX4571MAX4574 serial-interface controlled switches are ideal for multimedia applications. Each device features 35&...

MAX4574 General Description

The MAX4571MAX4574 serial-interface controlled switches are ideal for multimedia applications. Each device features 35Ω max on-resistance, -90dB audio off-isolation at 20kHz, -60dB video off-isolation at 1.0MHz, and "clickless" mode operation for audio applications.

The MAX4571/MAX4573 contain eleven SPST switches, while the MAX4572/MAX4574 contain two SPST switches and six SPDT switches. The MAX4571/MAX4572 fea- ture a 2-wire, I2C™-compatible serial interface. The MAX4573 / MAX4574 feature a 3-wire, SPI™/QSPI™/ MICROWIRE™-compatible serial interface. All four parts are available in 28-pin QSOP, SSOP, and wide SO packages and operate over the commercial and extended temperature ranges.

MAX4574 Maximum Ratings

V+ to GND................................................................-0.3V to +6V
NO_ _, COM_, DOUT to GND (Note 1) ........-0.3V to (V+ + 0.3V)
SCL, SDA, CS, SCLK, DIN, A0, A1 to GND..............-0.3V to +6V
Continuous Current into Any Terminal ..............................±10mA
Peak Current (pulsed at 1ms, 10% duty cycle)................±50mA
Continuous Power Dissipation (TA = +70°C)
QSOP (derate 10.8mW/°C above +70°C) ...................860mW
SSOP (derate 9.5mW/°C above +70°C) .....................762mW
Wide SO (derate 12.5mW/°C above +70°C).............1000mW
Operating Temperature Ranges
MAX457_C_ _ ....................................................0°C to +70°C
MAX457_E_ _..................................................-40°C to +85°C
Storage Temperature Range .......................-65°C to +160 °C
Lead Temperature (soldering, 10sec) ...........................+300°C

MAX4574 Features

* Selectable Soft Switching Mode for "Clickless"
     Audio Operation
* 35Ω max On-Resistance
* -90dB Audio Off-Isolation at 20kHz
    -50dB Video Off-Isolation at 10MHz
* -90dB Audio Crosstalk at 20kHz
    -52dB Video Crosstalk at 10MHz
* Serial Interface
    2-Wire, Fast-Mode, I2C-Compatible (MAX4571/72)
    3-Wire, SPI/QSPI/MICROWIRE-Compatible (MAX4573/74)
* Single-Supply Operation from +2.7V to +5.25V

MAX4574 Typical Application

Set-Top Boxes Audio Systems
PC Multimedia Boards Video Conferencing Systems

MAX4574 Connection Diagram

MAX4574 datasheet

MAX4574
PDF/DataSheet Download

Datasheet: MAX4574
File Size: 322735 KB
Manufacturer: Maixm
Click here to Download
