Purchase MAX 7000B, In-stock MAX 7000B From SeekIC.
Part Number: MAX 7000B
Description: MAX 7000B devices are high-density, high-performance devices based on Altera's second-generation MAX a...
- Table of contents:
MAX 7000B
-
Suppliers
DataSheet
General Description
MAX 7000B General Description
MAX 7000B devices are high-density, high-performance devices based on Altera's second-generation MAX architecture. Fabricated with advanced CMOS technology, the EEPROM-based MAX 7000B devices operate with a 2.5-V supply voltage and provide 600 to 10,000 usable gates, ISP, pin-to-pin delays as fast as 3.5 ns, and counter speeds up to 303.0 MHz. See Table 2.
MAX 7000B Features
`High-performance 2.5-V CMOS EEPROM-based programmable logic
devices (PLDs) built on second-generation Multiple Array MatriX
(MAX®) architecture (see Table 1)
Pin-compatible with the popular 5.0-V MAX 7000S and 3.3-V MAX 7000A device families
High-density PLDs ranging from 600 to 10,000 usable gates
3.5-ns pin-to-pin logic delays with counter frequencies in excess of 303.0 MHz
`Advanced 2.5-V in-system programmability (ISP)
Programs through the built-in IEEE Std. 1149.1 Joint Test Action
Group (JTAG) interface with advanced pin-locking capability
Enhanced ISP algorithm for faster programming
ISP_Done bit to ensure complete programming
Pull-up resistor on I/O pins during in-system programming
ISP circuitry compliant with IEEE Std. 1532
devices (PLDs) built on second-generation Multiple Array MatriX
(MAX®) architecture (see Table 1)
Pin-compatible with the popular 5.0-V MAX 7000S and 3.3-V MAX 7000A device families
High-density PLDs ranging from 600 to 10,000 usable gates
3.5-ns pin-to-pin logic delays with counter frequencies in excess of 303.0 MHz
`Advanced 2.5-V in-system programmability (ISP)
Programs through the built-in IEEE Std. 1149.1 Joint Test Action
Group (JTAG) interface with advanced pin-locking capability
Enhanced ISP algorithm for faster programming
ISP_Done bit to ensure complete programming
Pull-up resistor on I/O pins during in-system programming
ISP circuitry compliant with IEEE Std. 1532
MAX 7000B Connection Diagram
MAX002
