SeekIC No. : 003425049 Detail

MAZ8390GML: DIODE ZENER 39V 150MW SMINI-2

MAZ8390GML Data Sheet

Get Latest Price

Part Number:: MAZ8390GML
Mfg:
Supply Ability:: 5000

Price Break

Qty
1~5000

Unit Price
Negotiable

Processing time
15 Days

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2025/12/5

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

MAZ8024 evaluate
Features: • Extremely low noise voltage caused from the diode (2.4V to 39V,1/3 to 1/10 of ou...
MAZ802400L evaluate
DIODE ZENER 2.4V 150MW S-MINI 2P
MAZ8024G0L evaluate
DIODE ZENER 2.4V 150MW S-MINI 2P

Product Details

Quick Details

Series:	-	Manufacturer:	Panasonic Electronic Components - Semiconductor Products
Voltage - Zener (Nom) (Vz):	39V	Voltage - Forward (Vf) (Max) @ If:	1V @ 10mA
Emitter- Base Voltage VEBO :	- 3 V	Current - Reverse Leakage @ Vr:	50nA @ 30V
Tolerance:	±5%	Power - Max:	150mW
Impedance (Max) (Zzt):	300 Ohm	Mounting Type:	Surface Mount
Package / Case:	SC-90, SOD-323F	Supplier Device Package:	SMini2-F3

Description

Series: -
Tolerance: ±5%
Mounting Type: Surface Mount
Voltage - Zener (Nom) (Vz): 39V
Packaging: Cut Tape (CT)
Package / Case: SC-90, SOD-323F
Impedance (Max) (Zzt): 300 Ohm
Power - Max: 150mW
Manufacturer: Panasonic Electronic Components - Semiconductor Products
Voltage - Forward (Vf) (Max) @ If: 1V @ 10mA
Supplier Device Package: SMini2-F3
Current - Reverse Leakage @ Vr: 50nA @ 30V

Parameters:

Technical/Catalog Information	MAZ8390GML
Vendor	Panasonic - SSG
Category	Discrete Semiconductor Products
Voltage - Zener (Nom) (Vz)	39V
Power - Max	150mW
Impedance (Max) (Zzt)	300 Ohm
Voltage - Forward (Vf) (Max) @ If	1V @ 10mA
Current - Reverse Leakage @ Vr	50nA @ 30V
Tolerance	-
Mounting Type	Surface Mount
Package / Case	S-Mini 2P
Packaging	Tape & Reel (TR)
Operating Temperature	-55°C ~ 150°C
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	MAZ8390GML MAZ8390GML MAZ8390GMLTR ND MAZ8390GMLTRND MAZ8390GMLTR
