MBRB1545CTG

MBR Series Datasheet download

Five Points

Part Number: MBRB1545CTG

Category: Discrete Semiconductor Products

MFG: ON Semiconductor





Descriptions: DIODE SCHOTTKY 45V 7.5A D2PAK

Price Break

1
10
100
250
500
1000
2500
5000

Unit Price

1.13000
1.04300
.86940
.73028
.62596
.52164
.46948
.45209

Extended Price

1.13
10.43
86.94
182.57
312.98
521.64
1173.70
2260.45

(All prices are in USD) Prices for reference only
Urgent Purchase

MBRB1545CTG General Description

DIODE SCHOTTKY 45V 7.5A D2PAK

MBRB1545CTG Parameters

Technical/Catalog InformationMBRB1545CTG
VendorON Semiconductor
CategoryDiscrete Semiconductor Products
Diode Type Schottky
Diode Configuration1 Pair Common Cathode
Voltage - DC Reverse (Vr) (Max)45V
Current - Average Rectified (Io) (per Diode)7.5A
Voltage - Forward (Vf) (Max) @ If570mV @ 7.5A
Current - Reverse Leakage @ Vr100A @ 45V
Reverse Recovery Time (trr)-
SpeedFast Recovery =< 500ns, > 200mA (Io)
Mounting TypeSurface Mount
Package / CaseD&sup2;Pak, SMD-220, TO-263 (2 leads + tab)
PackagingTube
Drawing Number*
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names MBRB1545CTG
MBRB1545CTG
MBRB1545CTGOS ND
MBRB1545CTGOSND
MBRB1545CTGOS

MBRB1545CTG datasheet
