Purchase MC100EP221FA, In-stock MC100EP221FA From SeekIC.
Part Number: MC100EP221FA
Description: The MC100EP221 is a low skew 1to20 differential driver, designed with clock distribution in mind. It a...
- Table of contents:
MC100EP221FA
-
Suppliers
DataSheet
General Description
MC100EP221FA General Description
The MC100EP221 is a low skew 1to20 differential driver, designed with clock distribution in mind. It accepts two clock sources into an input multiplexer. The input signals can be either differential or singleended if the VBB output is used. The selected signal is fanned out to 20 identical differential outputs.
MC100EP221FA Features
` 150ps ParttoPart Skew
` 50ps OutputtoOutput Skew
` Differential Design
` VBB Output
` Voltage and Temperature Compensated Outputs
` Low Voltage VEE Range of 2.375 to 3.8V
` 75k Input Pulldown Resistors
` 50ps OutputtoOutput Skew
` Differential Design
` VBB Output
` Voltage and Temperature Compensated Outputs
` Low Voltage VEE Range of 2.375 to 3.8V
` 75k Input Pulldown Resistors
MC100EP221FA Connection Diagram
MC100EP221FA
PDF/DataSheet Download
- Datasheet: MC100EP221FA
- File Size: 88556 KB
- Manufacturer: MOTOROLA [Motorola, Inc]
- Click here to Download
