Five Points

Part Number: MC10H106



MFG: mot

Package Cooled: PLCC



Description: The MC10H106 is a triple 433 input NOR gate. This 10H part is a functional/pinout duplication of the standard MECL 10K ...


Urgent Purchase

MC10H106 General Description


The MC10H106 is a triple 433 input NOR gate. This 10H part is a functional/pinout duplication of the standard MECL 10K family part, with 100% improvement in propagation delay and no increase in power supply current.

MC10H106 Features

•Propagation Delay, 1.0 ns Typical
•Improved Noise Margin 150 mV (Over Operating Voltage and Temperature Range)
•Voltage Compensated
•MECL 10KCompatible

MC10H106 Connection Diagram

MC10H106 Connection Diagram
