Part Number: MC10H107



MFG: mot

Package Cooled: PLCC



Description: The MC10H107 is a triple 2input exclusive OR/NOR gate. This MECL 10H part is a functional/pinout duplication of the sta...


Urgent Purchase

MC10H107 General Description


The MC10H107 is a triple 2input exclusive OR/NOR gate. This MECL 10H part is a functional/pinout duplication of the standard MECL 10K family part, with 100% improvement in propagation delay, and no increase in powersupply current.

MC10H107 Features

•Propagation Delay, 1.0 ns Typical
•Power Dissipation 35 mW/Gate Typical (same as MECL 10K)
•Improved Noise Margin 150 mV (Over Operating Voltage and Temperature Range)
•Voltage Compensated
•MECL 10KCompatible

MC10H107 Connection Diagram

MC10H107 Connection Diagram
