MC10H352

The MC10H352 is a quad translator for interfacing data between a CMOS logic section and the PECL section of digital systems when only a +5.0 Vdc power supply is available. The MC10H352 has CMOS compatible inputs and PECL complementary openemitter outputs that llow use as an inverting/noninverting translator or as a differential line driver. When the common strobe input is at a low logic level, it forces all true outputs to the PECL low logic state ( +3.2 V) and all inverting outputs to the PECL high logic state ( +4.1 V).

The MC10H352 can also be used with the MC10H350 to transmit and receive CMOS information differentially via balanced twisted pair lines.
• Single +5.0 V Power Supply
• All V_CC Pins Isolated On Chip
• Differentially Drive Balanced Lines
• t_pd = 1.3 nsec Typical
