Part Number: MC14001UB
MFG: MOT
Package Cooled: DIP
D/C: 06+
Description: Symbol Parameter Value
MC14001UB General Description
| Symbol | Parameter | Value | Unit |
| VDD | DC Supply Voltage Range | −0.5 to +18.0 | V |
| Vin, Vout | Input or Output Voltage Range (DC or Transient) |
−0.5 to VDD + 0.5 | V |
| Iin, Iout | Input or Output Current (DC or Transient) per Pin |
±10 | mA |
| PD | Power Dissipation, per Package (Note 1) |
500 | mW |
| TA | Ambient Temperature Range | −55 to +125 | |
| Tstg | Storage Temperature Range | −65 to +150 | |
| TL | Lead Temperature (8−Second Soldering) |
260 |
MC14001UB Features
• Linear and Oscillator Applications
• Capable of Driving Two Low−Power TTL Loads or One
Low−Power Schottky TTL Load Over the Rated Temperature Range
• Double Diode Protection on All Inputs
• Pin−for−Pin Replacements for Corresponding CD4000 Series UB
Suffix Devices
• Pb−Free Packages are Available*
MC14001UB Connection Diagram
MC14001UB
