MC14008BDR2G

Logic Adder & Subtractor LOG CMOS ARTH OP 4BIT

product image

MC14008BDR2G Picture
See larger image
SeekIC No. : 00447309 Detail

MC14008BDR2G: Logic Adder & Subtractor LOG CMOS ARTH OP 4BIT

MC14008BDR2G Data Sheet

floor Price/Ceiling Price

US $ .3~.46 / Piece | Get Latest Price
Part Number:
MC14008BDR2G
Mfg:
ON Semiconductor
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~100
  • 100~500
  • Unit Price
  • $.46
  • $.39
  • $.35
  • $.3
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Logic Family : 4000 Package / Case : SOIC-16
High Level Output Current : - 4.2 mA (Min) Low Level Output Current : 4.2 mA (Min)
Propagation Delay Time : 800 ns at 5 V, 320 ns at 10 V, 230 ns at 15 V Operating Supply Voltage : 3.3 V, 5 V, 9 V, 12 V, 15 V
Maximum Power Dissipation : 500 mW Maximum Operating Temperature : + 125 C
Minimum Operating Temperature : - 55 C Packaging : Reel

Description

Maximum Operating Temperature : + 125 C
Package / Case : SOIC-16
Minimum Operating Temperature : - 55 C
Logic Family : 4000
High Level Output Current : - 4.2 mA (Min)
Low Level Output Current : 4.2 mA (Min)
Propagation Delay Time : 800 ns at 5 V, 320 ns at 10 V, 230 ns at 15 V
Operating Supply Voltage : 3.3 V, 5 V, 9 V, 12 V, 15 V
Maximum Power Dissipation : 500 mW
Packaging : Reel


Parameters:

Technical/Catalog InformationMC14008BDR2G
VendorON Semiconductor
CategoryIntegrated Circuits (ICs)
Logic TypeBinary Full Adder
Mounting TypeSurface Mount
Package / Case16-SOIC
Supply Voltage3 V ~ 18 V
PackagingTape & Reel (TR)
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names MC14008BDR2G
MC14008BDR2G
