Part Number: MC14024B



MFG: MOT

Package Cooled: DIP-14



Description: The MC14024B is a 7stage ripple counter with short propagation delays and high maximum clock rates. The Reset input has...


Urgent Purchase

MC14024B General Description


The MC14024B is a 7stage ripple counter with short propagation delays and high maximum clock rates. The Reset input has standard noise immunity, however the Clock input has increased noise immunity due to Hysteresis. The output of each counter stage is buffered.
* Diode Protection on All Inputs
* Output Transitions Occur on the Falling Edge of the Clock Pulse
* Supply Voltage Range = 3.0 Vdc to 18 Vdc
* Capable of Driving Two Lowpower TTL Loads or One Lowpower
Schottky TTL Load Over the Rated Temperature Range
* PinforPin Replacement for CD4024B

MC14024B Connection Diagram
