MC14553BCP

Counter Shift Registers 3-18V 3-Digit BCD

product image

MC14553BCP Picture
See larger image
SeekIC No. : 00421964 Detail

MC14553BCP: Counter Shift Registers 3-18V 3-Digit BCD

MC14553BCP Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
MC14553BCP
Mfg:
ON Semiconductor
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/17

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Counter Type : BCD Counting Sequence : Up
Number of Circuits : 3 Package / Case : PDIP-16
Logic Family : 14553 Logic Type : CMOS
Number of Input Lines : 1 Propagation Delay Time : 1800 ns, 1000 ns, 400 ns
Maximum Operating Temperature : + 125 C Minimum Operating Temperature : - 55 C
Packaging : Tube

Description

Output Type :
Maximum Operating Temperature : + 125 C
Minimum Operating Temperature : - 55 C
Logic Type : CMOS
Packaging : Tube
Counting Sequence : Up
Number of Input Lines : 1
Package / Case : PDIP-16
Number of Circuits : 3
Counter Type : BCD
Logic Family : 14553
Propagation Delay Time : 1800 ns, 1000 ns, 400 ns


Pinout

Connection Diagram Connection Diagram


Specifications

Symbol
Parameter
Value
Unit
VDD
 DC Supply Voltage Range
0.5 to +18.0
V
Vin, Vout
 Input or Output Voltage Range
(DC or Transient)
0.5 to VDD + 0.5
V
Iin
 Input Current
(DC or Transient) per Pin
±10
mA
Iout
 Output Current
(DC or Transient) per Pin
+20
mA
PD
 Power Dissipation,
per Package (Note 2.)
500
mW
TA
 Ambient Temperature Range
55 to +125
°C
Tstg
 Storage Temperature Range
65 to +150
°C
TL
 Lead Temperature
(8Second Soldering)
260
°C



Parameters:

Technical/Catalog InformationMC14553BCP
VendorON Semiconductor
CategoryIntegrated Circuits (ICs)
Logic TypeBCD Counter
Trigger TypeNegative Edge
Voltage - Supply-
Number of Bits per Element4
Number of Elements1 - Single
DirectionUp
Mounting TypeThrough Hole
Package / Case16-DIP
ResetAsynchronous
PackagingTube
Operating Temperature-55°C ~ 125°C
Count Rate7MHz
TimingSynchronous
Lead Free StatusContains Lead
RoHS StatusRoHS Non-Compliant
Other Names MC14553BCP
MC14553BCP
MC14553BCPOS ND
MC14553BCPOSND
MC14553BCPOS
