MC1456

The MC1456 is a kind of silicon monolithic integated circuit which designed for use as a summing amplifier, integraton or emplifier with operating cherecteristi as a function of the external feedback components.

The features of MC1456 can be summarized as (1)low input bias current- 15 nA max 2; (2)low input offset current- 2.0 nA max; (3)Low Input Offset Voltage - 4.0 mV max; (4)fast slew rate - 2.5 V/s typ; (5)large power bandwidth - 40 kHz typ; (6)law power consumption - 45 mW max; (7)offset voltage null capability; (8)output short-circuit protection; (9)input over-voltage protection.

The absolute maximum ratings of MC1456 are (1)power supply voltage VCC/VEE: +18/-18 Vdc; (2)differential input voltage range VIDR: ±VCC Volts; (3)common-mode range VICR: ±VCC Volts; (4)load current IL: 20mA; (5)output short circle duration tS: continous; (6)power dissipation (package limitation)/derate ahove TA =+25°C PD : 680 mW/4.6mW/°C; (7)operating temperature range TA: 0 to +70°C; (8)starage temperature range Tstg: -65 to +150°C.
