MC1489 Product Image

MC1 Series Datasheet download

Five Points

Part Number: MC1489



MFG: MOT

Package Cooled: SOP14



Description: These devices are monolithic low-power Schottky quadruple line receivers designed to satisfy the requirements of the...


Urgent Purchase

MC1489 General Description


These devices are monolithic low-power Schottky quadruple line receivers designed to satisfy the requirements of the standard interface between data-terminal equipment and data-communica- tion equipment as defined by TIA/EIA-232-F. A separate response-control (CONT) terminal is provided for each receiver. A resistor or a resistor and bias-voltage source can be connected between this terminal and ground to shift the input threshold levels. An external capacitor can be connected between this terminal and ground to provide input noise filtering.

The SN55189 and SN55189A are characterized for operation over the full military temperature range of 55°C to 125°C. The MC1489,
MC1489A, SN75189, and SN75189A are characterized for operation from 0°C to 70°C.

MC1489 Maximum Ratings

Supply voltage, VCC (see Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 V
Input voltage, VI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±30 V
Output voltage, IO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 20 mA
Continuous total power dissipation . . . . . . . .  See Dissipation Rating Table
Operating free-air temperature range, TA: SN55189,   . .  . . 55°C to 125°C
MC1489, MC1489A, SN75189, SN75189A . . . . . . .  . .  . .  . .  . . . 0°C to 70°C
Storage temperature range, Tstg . . . . . . . . . . . . . . . . . . . . . 65°C to 150°C
Case temperature for 60 seconds, FK package . . . . . . . . . . . . . . . . .  . 260°C
Lead temperature 1,6 mm (1/16 inch) from case for 60 seconds: J or W package . . . 300°C
Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: D, N, or NS package . 260°C

MC1489 Features

 Input Resistance...3 kΩ to 7 kΩ
 Input Signal Range... ±30 V
 Operate From Single 5-V Supply
 Built-In Input Hysteresis (Double Thresholds)
 Response Control that Provides:
 Input Threshold Shifting
 Input Noise Filtering
 Meet or Exceed the Requirements of
 TIA/EIA-232-F and ITU Recommendation V.28
 Fully Interchangeable With MotorolaMC1489 and MC1489A

MC1489 Connection Diagram

MC1489 Connection Diagram

MC1489 datasheet
