MC33701
-
Suppliers
DataSheet
General Description
MC33701 General Description
MC33701 Maximum Ratings
| Supply Voltage | VIN1 , V IN2 | -0.3 to 7.0 | V |
| Switching Node Voltage | VSW | -1.0 to 7.0 | V |
| Buck Regulator Bootstrap Input Voltage (BOOT - SW) | VIN(BOOT) | -0.3 to 8.5 | V |
| Boost Regulator Output Voltage | VBST | -0.3 to 8.5 | V |
| Boost Regulator Drain Voltage | VBD | -0.3 to 9.5 | V |
| RST Drain Voltage | VRST | -0.3 to 7.0 | V |
| Enable Terminal Voltage at EN1, EN2 | VEN | -0.3 to 7.0 | V |
| Logic Terminal Voltage at SDA, SCL | VLOG | -0.3 to 7.0 | V |
|
Analog Terminal Voltage LDRV, LCMP, CS |
VOUTVLIN | -0.3 to 7.0 -0.3 to 8.5 |
V |
| Terminal Voltage at CLKSEL, ADDR, RT, FREQ, VDDI, CLKSYN, INV LFB |
VLOGIC | -0.3 to 3.6 | V |
| ESD Voltage (1) Human Body Mod Machine Model |
VESD | ±2000 ±200 |
V |
| Thermal Ratings | V | ||
| Storage Temperature | TSTG | -65 to 150 | |
| Lead Soldering Temperature (2) |
TSOLDER | 260 | |
| Maximum Junction Temperature | TJMAX | 125 | |
| hermal Resistance(3) ,(4) Junction to Ambient (Single Layer) (3), (4) Junction to Ambient (Four Layers) |
RJA | 70 55 |
/W |
| Thermal Resistance, Junction to Base (5) |
RJB | 18 | /W |
| Operational Package Temperature (Ambient Temperature) | TA | -40 to 85 |
MC33701 Features
·Operating Voltage from 2.8 V to 6.0 V
· High-Accuracy Output Voltages
·Fast Transient Response
·Switcher Output Current Up to 1.5 A
·Undervoltage Lockout and Overcurrent Protection
· Enable Inputs and Programmable Watchdog Timer
·Voltage Margining via I 2CTM Bus
·Reset with Programmable Power-ON Delay
· Pb-Free Packaging Designated by Suffix Code EK
I2 C is a trademark of Philips Corporation.
MC33701 Connection Diagram
