Position: Home > Datasheet list > MC5 Series > Index M > MC56F8037VLH
Electronica China

Purchase MC56F8037VLH, In-stock MC56F8037VLH From SeekIC.

MFG:Freescale Semiconductor  Category:Integrated Circuits (ICs)

MC56F8037VLH

MC5 Series Datasheet download

Five Points

Part Number: MC56F8037VLH

Category: Integrated Circuits (ICs)

MFG: Freescale Semiconductor





Descriptions: IC DSP 16BIT DUAL 64-LQFP

Price Break

1
25
100
1000

Unit Price

6.82000
4.93720
4.66930
4.43520

Extended Price

6.82
123.43
466.93
4435.20

(All prices are in USD) Prices for reference only
Urgent Purchase

MC56F8037VLH General Description

IC DSP 16BIT DUAL 64-LQFP

MC56F8037VLH Parameters

Technical/Catalog InformationMC56F8037VLH
VendorFreescale Semiconductor
CategoryIntegrated Circuits (ICs)
Program Memory Size32K x 16
RAM Size8K x 8
Number of I /O53
Package / Case64-LQFP
Speed32MHz
Controller Series56F8xxx
Oscillator TypeInternal
PackagingTray
Program Memory TypeFLASH
EEPROM Size-
Core Processor56800
Data ConvertersA/D 16x12b; D/A 2x12b
Core Size16-Bit
Operating Temperature-40°C ~ 105°C
ConnectivityCAN, I²C, SCI, SPI
PeripheralsPOR, PWM, WDT
Voltage - Supply (Vcc/Vdd)3 V ~ 3.6 V
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names MC56F8037VLH
MC56F8037VLH

MC56F8037VLH datasheet

MC56F8037VLH
PDF/DataSheet Download

  • Datasheet: MC56F8037VLH
  • File Size: 2623346 KB
  • Manufacturer: FREESCALE [Freescale Semiconductor, Inc]
  • Click here to Download
