Purchase MC56F8167VPYE, In-stock MC56F8167VPYE From SeekIC.

MFG:Freescale Semiconductor  Category:Integrated Circuits (ICs)

MC56F8167VPYE Product Image

MC5 Series Datasheet download

Five Points

Part Number: MC56F8167VPYE

Category: Integrated Circuits (ICs)

MFG: Freescale Semiconductor





Descriptions: IC DSP 16BIT 40MHZ 160-LQFP

Price Break

40

Unit Price

15.40800

Extended Price

616.32

(All prices are in USD) Prices for reference only
Urgent Purchase

MC56F8167VPYE General Description

IC DSP 16BIT 40MHZ 160-LQFP

MC56F8167VPYE Parameters

Technical/Catalog InformationMC56F8167VPYE
VendorFreescale Semiconductor
CategoryIntegrated Circuits (ICs)
Program Memory Size544KB (544K x 8)
RAM Size32K x 8
Number of I /O76
Package / Case160-LQFP
Speed40MHz
Controller Series56F8xxx
Oscillator TypeExternal
PackagingTray
Program Memory TypeFLASH
EEPROM Size-
Core Processor56800
Data ConvertersA/D 16x12b
Core Size16-Bit
Operating Temperature-40°C ~ 105°C
ConnectivityEBI/EMI, SCI, SPI
PeripheralsPOR, PWM, WDT
Voltage - Supply (Vcc/Vdd)2.25 V ~ 2.75 V
Drawing Number375; 1259-01; ; 160
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names MC56F8167VPYE
MC56F8167VPYE

MC56F8167VPYE datasheet

MC56F8167VPYE
PDF/DataSheet Download

  • Datasheet: MC56F8167VPYE
  • File Size: 4447026 KB
  • Manufacturer: FREESCALE [Freescale Semiconductor, Inc]
  • Click here to Download
