Position: Home > Datasheet list > MC9 Series > Index M > MC9S08QE8CWL
Electronica China

Purchase MC9S08QE8CWL, In-stock MC9S08QE8CWL From SeekIC.

MFG:Freescale Semiconductor  Category:Integrated Circuits (ICs)

MC9S08QE8CWL

MC9 Series Datasheet download

Five Points

Part Number: MC9S08QE8CWL

Category: Integrated Circuits (ICs)

MFG: Freescale Semiconductor





Descriptions: IC MCU 8BIT 8K FLASH 28-SOIC

Price Break

1
25
100

Unit Price

1.67000
1.52280
1.36800

Extended Price

1.67
38.07
136.80

(All prices are in USD) Prices for reference only
Urgent Purchase

MC9S08QE8CWL General Description

IC MCU 8BIT 8K FLASH 28-SOIC

MC9S08QE8CWL Parameters

Technical/Catalog InformationMC9S08QE8CWL
VendorFreescale Semiconductor
CategoryIntegrated Circuits (ICs)
Program Memory Size8K x 8
RAM Size512 x 8
Number of I /O22
Package / Case28-SOIC (7.5mm Width)
Speed20MHz
Controller SeriesHCS08
Oscillator TypeInternal
PackagingTube
Program Memory TypeFLASH
EEPROM Size-
Core ProcessorHCS08
Data ConvertersA/D 10x12b
Core Size8-Bit
Operating Temperature-40°C ~ 85°C
ConnectivityI²C, LIN, SCI, SPI
PeripheralsLVD, PWM, WDT
Voltage - Supply (Vcc/Vdd)1.8 V ~ 3.6 V
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names MC9S08QE8CWL
