MC9S12B128CFU

The MC9S12B128CFU is one member of the MC9S12B128 family which is designed as the 16 bit Flashbased microcontroller that is fully pin compatible and enable users to choose between different memory and peripheral options for scalable designs. And also this device is composed of standard on-chip peripherals including a 16-bit central processing unit (CPU12), up to 512K bytes of Flash EEPROM, 14K bytes of RAM, 4K bytes of EEPROM, two asynchronous serial communications interfaces (SCI), three serial peripheral interfaces (SPI), IIC-bus, an enhanced capture timer (ECT), two 8-channel 10-bit analog-to-digital converters (ADC), an eight-channel pulse-width modulator (PWM)

Features of the MC9S12B128CFU are:(1)Upward compatible with M68HC11 instruction set;(2)Single chip or expanded;(3)16 address/16 data wide or 16 address/8 data narrow modes;(4)16 address/16 data wide or 16 address/8 data narrow modes;(5)One or two 8-channel modules with 10-bit resolution depending on the package option;(6)External conversion trigger capability;(7)Flexible identifier filter programmable as 2 x 32 bit, 4 x 16 bit or 8 x 8 bit;(8)Each channel configurable as either input capture or output compare;(9)Programmable period and duty cycle;(10)One asynchronous serial communications interface (SCI).

The absolute maximum ratings of the MC9S12B128CFU can be summarized as:(1)I/O, Regulator and Analog Supply Voltage:0.3 to 6.5 V;(2)Digital Logic Supply Voltage:0.3 to 3.0 V;(3)PLL Supply Voltage:0.3 to 3.0 V;(4)Voltage difference VDDX to VDDR and VDDA:0.3 to 0.3 V;(5)Digital I/O Input Voltage:0.3 to 6.5 V;(6)Analog Reference:0.3 to 6.5 V;(7)XFC, EXTAL, XTAL inputs:0.3 to 3.0 V;(8)TEST input:0.3 to 10.0 V;(9)Operating Temperature Range (packaged): -40 to 125 °C;(10)Operating Temperature Range (junction): -40 to 140 °C;(11)Storage Temperature Range: -65 to 155 °C.

The electrical characteristics of the MC9S12B128CFU can be summarized as:(1)Human Body Model (HBM): 2000 V;(2)Machine Model (MM): 200 V;(3)Charge Device Model (CDM): 500 V. If you want to know more information such as the electrical characteristics about the MC9S12B128CFU, please download the datasheet in www.seekic.com or www.chinaicmart.com .
