MC9S12DG256

Features: • HCS12 Core 16-bit HCS12 CPUi. Upward compatible with M68HC11 instruction setii. Interrupt stacking and programmer's model identical to M68HC11iii. Instruction queueiv. Enhanced indexed addressing MEBI (Multiplexed External Bus Interface) MMC (Module Mapping Control) INT (Interrup...

product image

MC9S12DG256 Picture
See larger image
SeekIC No. : 004417416 Detail

MC9S12DG256: Features: • HCS12 Core 16-bit HCS12 CPUi. Upward compatible with M68HC11 instruction setii. Interrupt stacking and programmer's model identical to M68HC11iii. Instruction queueiv. Enhanced ind...

MC9S12DG256 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
MC9S12DG256
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/5/28

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• HCS12 Core
16-bit HCS12 CPU
i. Upward compatible with M68HC11 instruction set
ii. Interrupt stacking and programmer's model identical to M68HC11
iii. Instruction queue
iv. Enhanced indexed addressing
MEBI (Multiplexed External Bus Interface)
MMC (Module Mapping Control)
INT (Interrupt control)
BKP (Breakpoints)
BDM (Background Debug Mode)
• CRG
Low current Colpitts or Pierce oscillator
PLL
COP watchdog
Real time interrupt
Clock Monitor
• 8-bit and 4-bit ports with interrupt functionality
Digital filtering
Programmable rising or falling edge trigger
• Memory
256K Flash EEPROM
4K byte EEPROM
12K byte RAM
• Two 8-channel Analog-to-Digital Converters
10-bit resolution
External conversion trigger capability
• Three 1M bit per second, CAN 2.0 A, B software compatible modules
Five receive and three transmit buffers
Flexible identifier filter programmable as 2 x 32 bit, 4 x 16 bit or 8 x 8 bit
Four separate interrupt channels for Rx, Tx, error and wake-up
Low-pass filter wake-up function
Loop-back for self test operation
• Enhanced Capture Timer
16-bit main counter with 7-bit prescaler
8 programmable input capture or output compare channels
Four 8-bit or two 16-bit pulse accumulators
• 8 PWM channels
Programmable period and duty cycle
8-bit 8-channel or 16-bit 4-channel
Separate control for each pulse width and duty cycle
Center-aligned or left-aligned outputs
Programmable clock select logic with a wide range of frequencies
Fast emergency shutdown input
Usable as interrupt inputs
• Serial interfaces
Two asynchronous Serial Communications Interfaces (SCI)
Three Synchronous Serial Peripheral Interface (SPI)
• Byte Data Link Controller (BDLC)
SAE J1850 Class B Data Communications Network Interface Compatible and ISO Compatible for Low-Speed (<125 Kbps) Serial Data Communications in Automotive Applications
• Inter-IC Bus (IIC)
Compatible with I2C Bus standard
Multi-master operation
Software programmable for one of 256 different serial clock frequencies
• 112-Pin LQFP package
I/O lines with 5V input and drive capability
5V A/D converter inputs
Operation at 50MHz equivalent to 25MHz Bus Speed
Development support
Single-wire background debug™ mode (BDM)
On-chip hardware breakpoints


Pinout

Connection Diagram




Specifications

Absolute maximum ratings are stress ratings only. A functional operation under or outside those maxima is not guaranteed. Stress beyond those limits may affect the reliability or cause permanent damage of the device.

This device contains circuitry protecting against damage due to high static voltage or electrical fields; however, it is advised that normal precautions be taken to avoid application of any voltages higher than maximum-rated voltages to this high-impedance circuit. Reliability of operation is enhanced if unused inputs are tied to an appropriate logic voltage level (e.g., either VSS5 or VDD5).

Num Rating Symbol Min Max Unit
1 I/O, Regulator and Analog Supply Voltage VDD5 -0.3 6.0 V
2 Digital Logic Supply Voltage 2 VDD -0.3 3.0 V
3 PLL Supply Voltage 2 VDDPLL -0.3 3.0 V
4 Voltage difference VDDX to VDDR and VDDA DVDDX -0.3 0.3 V
5 Voltage difference VSSX to VSSR and VSSA DVSSX -0.3 0.3 V
6 Digital I/O Input Voltage VIN -0.3 6.0 V
7 Analog Reference VRH, VRL -0.3 6.0 V
8 XFC, EXTAL, XTAL inputs VILV -0.3 3.0 V
9 TEST input VTEST -0.3 10.0 V
10 Instantaneous Maximum Current
Single pin limit for all digital I/O pins 3		 ID -25 +25 mA
11 Instantaneous Maximum Current
Single pin limit for XFC, EXTAL, XTAL4		 IDL -25 +25 mA
12 Instantaneous Maximum Current
Single pin limit for TEST 5		 IDT -0.25 0 mA
13 Storage Temperature Range Tstg 65 155



Description

This section describes signals that connect off-chip. It includes a pinout diagram, a table of signal properties, and detailed discussion of signals. MC9S12DG256 is built from the signal description sections of the Block User Guides of the individual IP blocks on the device.
