MCM69L817ZP7_1195048 General Description


The SP8530 is a two channel simultaneous sampling, 12-Bit serial out data acquisition system.

The device contains a high speed 12-Bit analog to digital converter, internal reference, and sample/hold circuitry for both channels. The 8530 is available in 16-pin PDIP and SOIC packages, specified over Commercial and Industrial temperature ranges.

MCM69L817ZP7_1195048 Maximum Ratings

(TA=+25 unless otherwise noted) ..............................................
VDD to DGND ...............................................-0.3V to +7V
VDA to AGND ............................................... -0.3V to +7V
Vin to AGND ...................................... -0.3V to VDA +0.3V
Digital Input to VSS ............................ -0.3V to VDD+0.3V
Digital Output to VSS .......................... -0.3V to VDD+0.3V
Operating Temp. Range
Commercial (J,K Version) ................................. 0 to 70
Industrial (A,B Version) .............................. -40 to +85
Storage Temperature ............................................... -65°C to 150
Lead Temperature(Solder 10sec) ........................................ +300
Power Dissipation to +70 ................................................ 500mW
Derate Above 70 ......................................................... 10mW/

MCM69L817ZP7_1195048 Features

` Patented Simultaneous Sampling of 2 channels (Patent # 5,638,072)
` 12 Bit Resolution
` Single +5Volt Supply
` Internal Reference, 1.25V
` Unipolar 0 to +2.5 Volt Input Range
` Fast, 7.75 s Conversion Time Both Channels
` Fast Power Shutdown/Turn-On Mode
` 3-Wire Synchronous Serial High Speed Interface
` True Differential Measurements
` 2mA Shutdown Mode (10W)
` Low Power CMOS 60mW typical



MCM69L817ZP7_1195048 Connection Diagram
